LiFePO4 (LFP)
IFR-18500-1200
lifepo4-18500-1200mah-battery-cell
3.2V nominal voltage with 1200mAh rated capacity.
LiFePO4 chemistry in 18500 format for rechargeable battery assemblies.
Available for OEM pack integration, application matching and engineering review.
Request Engineering Review
Product Data
Key Specifications
Core parameters for fast product comparison and initial selection.
Chemistry
LiFePO4 (LFP)
Size
18500
Nominal Voltage
3.2V V
Typical Capacity
1200mAh mAh
Minimum Capacity
1150mAh mAh
Dimensions
D= 18.55+0 -0.3mm H:65.35 ± 0.1mm
Weight
64
Use Cases
Typical Applications
Common application categories associated with this product.
Application Fit
Tell us your voltage, capacity, quantity and operating requirements for an engineering recommendation.
Emergency LightingIndustrial Backup / UPSMedicalPersonal Care
Electrical Performance
Performance
Verified performance values are displayed only when available.
Internal Resistance
≤60mΩ
Max Continuous Discharge
3.6
Peak Discharge
3.6
Cycle Life
≥ 500 Cycles
Operating Temperature
-20°C to +60°C
Integration
Mechanical Integration
Dimensions and integration details for enclosure, connection and installation planning.
Dimensions
D= 18.55+0 -0.3mm H:65.35 ± 0.1mm
Weight
64
Housing Type
Shrink Wrap
IP Rating
N/A
Flexible Supply
Customization Options
Available OEM/ODM options and commercial parameters for project sourcing.
Discuss Custom Battery RequirementsOEM / ODM SupportedConfiguration and supply requirements can be reviewed with our engineering team.
Engineering Support
Get an Engineering Review
Send your voltage, capacity, discharge profile, quantity and application requirements.
Start Your RFQ
Our team will review product fit and customization feasibility.
Send Requirements for Review
